Detailed explanation of the working principle of linear regulated power supply
According to the working state of the regulating tube, we often divide the regulated power supply into two categories: linear regulated power supply and switch regulated power supply. In addition, there is a small power supply that uses a voltage regulator.
The linear regulated power supply mentioned here refers to a DC regulated power supply that operates in a linear state with an adjustment tube. The adjustment tube works in a linear state, which can be understood as follows: RW (see analysis below) is continuously variable, that is, linear. In switching power supplies, the switch transistor (commonly referred to as the adjustment transistor in switching power supplies) operates in two states: on - with very low resistance; Off - The resistance is high. The tube working in the on/off state is clearly not in a linear state.
Linear regulated power supply is a relatively early type of DC regulated power supply. The characteristics of linear regulated DC power supply are: the output voltage is lower than the input voltage; Fast response speed and small output ripple; Low noise generated by work; Low efficiency (LDO, which is often seen nowadays, appears to solve efficiency problems); High heat generation (especially high-power power sources) indirectly increases thermal noise to the system.
Working principle: Let's first use the following diagram to illustrate the principle of voltage regulation in a linear regulated power supply.
The variable resistor RW and the load resistor RL form a voltage divider circuit, with an output voltage of:
Uo=Ui × RL/(RW+RL), therefore, by adjusting the size of RW, the output voltage can be changed. Please note that in this equation, if we only look at the value change of the adjustable resistor RW, the output of Uo is not linear, but if we look at RW and RL together, it is linear. Also note that our diagram does not depict the RW lead end as connected to the left, but rather on the right. Although there may not be much difference in formula, drawing it on the right precisely reflects the concepts of "sampling" and "feedback" - in reality, the vast majority of power sources work in sampling and feedback modes, and feedforward methods are rarely used, or simply auxiliary methods.
Let's continue: if we replace the variable resistor in the figure with a transistor or field-effect transistor, and control the resistance value of this "variable resistor" by detecting the output voltage, so that the output voltage remains constant, we achieve the goal of voltage stabilization. This transistor or field-effect transistor is used to adjust the voltage output size, so it is called an adjustment transistor.
Due to the fact that the adjustment tube is connected in series between the power supply and the load, it is called a series regulated power supply. Correspondingly, there is a parallel regulated power supply, which adjusts the output voltage by paralleling the regulating tube with the load. A typical reference voltage regulator TL431 is a type of parallel regulated power supply. The meaning of parallel connection is to ensure the "stability" of the emitter voltage of the attenuation amplifier tube through shunt, as shown in Figure 2. Perhaps this figure does not immediately indicate that it is "parallel", but upon closer inspection, it is indeed the case. However, it should be noted that the voltage regulator used here operates in its nonlinear region. Therefore, if it is considered a power source, it is also a nonlinear power source. For the convenience of everyone's understanding, let's look for a reasonably suitable diagram later until we can understand it concisely.
Due to the fact that the adjustment tube acts as a resistor and generates heat when current flows through the resistor, the adjustment tube operating in a linear state generally generates a large amount of heat, resulting in low efficiency. This is one of the main drawbacks of linear regulated power supplies. For a more detailed understanding of linear regulated power supplies, please refer to the analog electronic circuit textbook. Our main purpose here is to help everyone clarify these concepts and their relationships.
