Brief analysis of the characteristics of the metal melt pyrometer and its application
Molten metal pyrometer is a set of economic molten metal temperature measurement system, the instrument adopts simple overall design, the whole device can better meet the smelting, foundry and other industries in the melting process to quickly measure the temperature of molten metal using the requirements of the instrument and the appropriate thermocouples can be used with a variety of melting occasions such as steel, iron, copper, aluminium, zinc, etc. for rapid and precise temperature measurement. Pyrometer can use S, R, B and K type thermocouple measurement, to ensure the practicality of the instrument and excellent measurement accuracy. The compact housing design of the instrument meets the requirements for use in harsh environments. Meter provides fast and reliable measurement, bright digital display.
Instrument technical parameters:
1, meter temperature measurement range:
S-type (Pt10%Rh/Pt) 400--1760°C
R-type (Pt13%Rh/Pt) 400--1760 ℃
B-type (Pt30%Rh/Pt6%Rh) 600--1820°C
K-type (NiCr-Ni) 200-1400℃
2,Measurement mode: single point temperature measurement and continuous temperature measurement
3, temperature display: 4 LED digital display temperature
4,Measurement accuracy: ±1℃
5,Measurement status display: "ready", "measurement", "complete" three colour signal light indicator
6, measurement data output: standard RS232-TTY20mA current loop signal output
Standard RS232-V24V serial signal output
7, operating data: power requirements: 230/115, "10% -15%, 50/60Hz
Instrument power consumption: 14VA
Ambient temperature: 0-50°C
Instrument main features
1, special steel casting temperature measurement instrument
2, high cost-effective instrumentation
3, high measurement accuracy
4, single point / continuous temperature measurement function
Instrument output function:
1,Measurement status signal output - reed relay isolation
2,Measurement data output-RS232-TTY20mA current loop signal
3, S, R, B and K type thermocouple input instrument optional accessories:
4,Wireless data receiving module and supporting data receiving software package
5,Dedicated supporting display screen
6,Special matching stylus and external compensation wire
7,Dedicated supporting data printer
