How the magnification observation of the stereomicroscope can be adapted to different requirements
Stereo microscopes are used for stereoscopic inspection and observation of electronic parts\integrated circuit boards\turned-head tools\magnets etc. Based on the fact that these different objects under test need to be observed in different magnification states, how to adapt to these different requirements? It can be solved in several ways a. By optical performance b. Optional video observation c. By mechanical performance d. By light source illumination
Optical performance: according to the object to be observed by the observation requirements, through the selection of different eyepieces \ objective lenses to solve the problem of large magnification and large field of view. Only require large magnification, can be replaced by large magnification eyepieces and objective lenses, require to see a large field of view can be replaced by replacing the objective lens, reduce the eyepieces or change the eyepieces with a large field of view to meet the requirements.
Video observation: When optical magnification is not enough, electronic magnification can be used to compensate. When observing at the same time and wishing to be able to store and retain, we can choose video. There are various ways of video: A. directly through the monitor B. can be connected to a computer (through a digital CCD or analogue CCD image acquisition card) C. can be connected to a digital camera (different digital cameras should take into account the different interfaces and the compatibility with the microscope)
Mechanical performance: encounter some welding, assembly, large integrated circuit board inspection field and the working distance requirements, we can through the mechanical performance to solve, such as universal bracket, rocking arm bracket, large mobile platform and so on. With their performance characteristics, when the inspection of large objects directly through the bracket and platform can complete our inspection work. There is no need to move our object to be tested. For example: A company due to the inspection circuit board is relatively large and need to observe the subtle tilt, the circuit board is very difficult to move up, only through mechanical movement to complete the inspection work, the use of universal bracket can also meet these requirements.
Light source illumination: light source illumination on the ability to see the object under test plays a crucial role, when choosing the lighting must be based on the characteristics of the object under test itself (taking into account its light requirements, strong \ weak \ reflective, etc.) to choose the appropriate lighting tools and lighting methods. If the general body-viewing microscope comes with transmission, oblique illumination can not meet your lighting needs, we have also prepared for you LED cold light source lamp, ring light, single / double fibre-optic cold light source lamp and so on.
