Introduction to the Four Major Categories of Electrochemical Gas Detection Instruments
(1) The principle of the original battery type gas sensor (also known as the Cavani battery type gas sensor, fuel cell type gas sensor, or spontaneous cell type gas sensor) is the same as the dry battery we use, except that the carbon manganese electrode of the battery is replaced by a gas electrode Taking an oxygen detector as an example, oxygen is reduced at the cathode, and electrons flow through an ammeter to the anode, where lead metal is oxidized The magnitude of the current is directly related to the concentration of oxygen This sensor can effectively detect oxygen, sulfur dioxide, chlorine gas, etc
(2) Constant potential electrolytic cell type gas sensor, which is very effective for detecting reducing gases. Its principle is different from the original battery type sensor, and its electrochemical reaction occurs under the force of current. It is a true Coulomb analysis sensor This type of sensor has been successfully used in the detection of gases such as carbon monoxide, hydrogen sulfide, hydrogen, ammonia, hydrazine, etc. It is currently the mainstream sensor for toxic and harmful gas detectors
(3) The concentration battery type gas sensor, with electrochemically active gas on both sides of the electrochemical cell, spontaneously forms a concentration electromotive force, and the magnitude of the electromotive force is related to the concentration of the gas. Successful examples of such sensors are oxygen sensors for automobiles and solid electrolyte type carbon dioxide detectors
(4) Extreme current type gas sensor, there is a sensor for measuring oxygen concentration that uses the principle that the extreme current in the electrochemical cell is related to the carrier concentration to prepare an oxygen (gas) concentration sensor, which is used for oxygen detection in automobiles and oxygen concentration detection in molten steel
At present, the main suppliers of this type of sensor are all over the world, mainly in Germany, Japan, and the United States. Recently, several European suppliers have been added, including the United Kingdom and Switzerland China started early in this field, but the industrialization process has not been effective
