Laser ranging is fast and accurate. With the drop in price, more and more industrial places begin to use laser rangefinders for distance measurement. There are two types of laser rangefinders on the market: ordinary and explosion-proof. , So is it necessary to buy an explosion-proof laser rangefinder?
Whether you need to buy an explosion-proof laser rangefinder mainly depends on the application field of the laser rangefinder. For ordinary indoor and outdoor measurements, you do not need to buy an explosion-proof type, but if it is in explosive places such as gas plants, coking plants, petroleum, and chemical industries , For the measurement of material level, material level and liquid level, it is necessary to buy an explosion-proof laser distance meter.
Compared with the ordinary type, the explosion-proof laser rangefinder mainly has a higher protection level, which can be applied to various industrial places, the middle area of the explosive gas environment and the IIB class T6 group of zone I, as well as the explosive dangerous places.
Instructions for use of explosion-proof laser rangefinder
Explosion-proof mark: Ex ia IICT3 Ga
Protection class: IP54
Dust rating: IP5X to prevent harmful dust accumulation.
Waterproof grade: IPX4, no damage will be caused when the liquid is poured into the casing from any direction.
Range: 0.05-100m
Accuracy: +1.5mm
Measurement unit: m/in/f/ft+in
Laser class: Class 2M II
Laser Type: 635nm, < 1mW
Measurement functions: single measurement, continuous measurement, maximum/minimum measurement, area/volume measurement, indirect Pythagorean theorem measurement.
Display mode: buzzer, four-line lighting display.
Button Type: Soft Rubber Button
Button life: over 1 million times
Battery type: TypeAAA2*1.5V
Battery life: up to 5000 measurements
Operating temperature: 0°C~40°C
Storage temperature: -10°C~60°C
Historical data: 99 groups
