What do the symbols on the multimeter represent
Turntable identification, clockwise:
OFF shutdown, mV AC/DC millivolt voltage, V~AC voltage, V-DC voltage, Ω resistance,
Diode, continuity test, capacitance, frequency, triode magnification, temperature,
μA AC/DC microamps, mA AC/DC milliamps, A AC/DC amps, shutdown
The top row of buttons, from left to right:
SELECT range selection;
Hz/DUTY Hertz/signal duty cycle;
HOLD freeze, lock;
RANGE range selection;
REL read
Note that there is a string of letters 10sec MAX below the 10A logo, which is required to use this jack for measurement, and it is not allowed to exceed 10 seconds.
Other symbol meanings:
Ω Ohm measure resistance value
V-Voltage Measure DC voltage
V～Voltage Measure AC voltage
A-current measures DC current
A～Current Measure AC current
—≯—Diode Measure the polarity of the diode
hfe triode for measuring triode magnification β
