Automatic three-phase AC regulated power supply voltage stabilization characteristics

Features of automatic three-phase AC regulated power supply Simple finger-pull setting function. The voltage-stabilizing control board adopts a human-friendly operation setting method for setting the voltage-stabilizing rate, and the finger-pull switch is used for segmental setting, which is accurate and reliable. The main structure is the shell , silicon steel sheet, and induction coil, it can withstand both surge and nonlinear load impact, so it is durable and has a long service life. With anti-lightning, anti-surge protection function (optional).

Automatic three-phase AC regulated power supply characteristics

Simple finger-pull setting function, the voltage stabilization control board adopts a human-friendly operation setting method for setting the voltage stabilization rate, and uses the finger-pull switch for segmental setting, which is accurate and reliable.

The main structure is composed of shell, silicon steel sheet, and induction, which can withstand both surge and nonlinear load impact, so it is durable and has a long service life.

With anti-lightning, anti-surge protection function (optional).

Automatic three-phase AC regulated power supply voltage stabilization characteristics

★Overcome the shortcomings of autotransformer carbon brush voltage regulating models.

Manufactured by the principle of electromagnetic induction, no contact points, no carbon brush wear, no sparks and other shortcomings, low failure rate, high safety, maintenance-free replacement.

★Overcome the shortcomings of CNC SCR models

Using the magnetic field deflection angle to stabilize the voltage, there is no jump, no tap surge and waveform mutation, and the voltage is linearly adjusted.

Technical specification for automatic three-phase AC regulated power supply

Voltage regulation range: ±15% of rated input voltage (or customized according to customer requirements)

Output accuracy: ±0.5%～±1% (adjustable within ±10%)

Working frequency: 50/60Hz±5%

Use efficiency: more than 98%

Waveform distortion: sine wave without distortion

Overload capacity: 150% (60min) 300% (10min)

Working environment: Temperature -20°C～45°C Humidity 0%～90%

Coil temperature resistance: Class H 180°C

Equipment noise: full load ≤ 65dB (1M away from the box)

Insulation voltage: coil to conductor 2500V60S (≤10mA)

Insulation: ≤0.1Ω
