Fully automatic microscope features Fully automatic microscope working principle
Full-automatic microscope is a kind of high-tech product which adopts advanced centralised control technology and modular embedded structure, so as to realise the three-axis control of XYZ of the carrier stage and the automatic adjustment of the brightness of the light source, and to realise the full-automatic function of panoramic auto-scanning, auto-jigsaw puzzle, auto-positioning, synchronous browsing, remote remote control and so on through the software to achieve the aim of improving the working efficiency of the integration of the photoelectricity and the calculation of the high technology products.
Characteristics
Fully automatic microscope has the features of strong reliability, good stability, high precision, etc. It is an indispensable component of automatic microscopic image analysis equipment.
Working Principle
Fully automatic microscope adopts standard RS232 communication interface, users can easily adjust the field of view, focus and brightness of the microscope through computer control, relying on the control system's auto-focusing, XYZ three-axis motion automatic control, high and low magnification automatic conversion, etc. to achieve the specimen's bow-tie line-by-line motion scanning so as to realise the image of the multi-field-of-view, full-automatic measurement and analysis. Through modern communication technology, remote control of the microscope can also be realised.
Product performance and technical indicators
1. 30 degree hinged binocular observation head (55mm-75mm) with 360 degree rotation.
2. Eyepiece WF10X/WF23.
3.4X,10X,40X(S),100X(S)Oil infinity flat-field achromatic objective lens.
4.Double-layer moving stage, stage size 180X150mm, moving range: 75X50mm;.
5.N.A.1.25 Abbe spotting scope with variable column and colour filter, high brightness Köhler illumination.
6.Coarse adjustment, micro-movement coaxial focusing, using rack and pinion drive mechanism, micro-movement grid value of 0.002mm;
7.Adjustable brightness halogen lamp 12V/20W or LED light source.
8. three-axis maximum range of movement X-axis 75mm, Y-axis 55mm, Z-axis 25mm. load table to move the smallest step X-axis: 1.250μm. load table to move the smallest step Y-axis: 0.625μm. load table to move the smallest step Z-axis: 0.625μm.
9. XYZ three-axis origin high-precision photoelectric control, convenient memory coordinates, permanent, accurate return position.
10.XYZ three-axis fully automatic control, high precision, fast speed.
11. Light source automatic switch and brightness automatic control.
12. Static image traceability: after the collection of static images, browsing can be traced back to the image of the original mirror coordinates, dynamic, the original image immediately present.
13.100 times oil mirror under the automatic focusing, picking map clarity of up to 99% or more, to reach the professional level of manual focusing, picking map.
14.100 times oil mirror every minute auto-focus picking map not less than 50;.
15. According to the actual needs (dynamic and static, refresh speed, clarity) to choose a different layout of different pixels CCD.
