High voltage DC switching power supply technical specifications
The high-voltage DC switching power supply adopts switching power supply technology without power frequency transformers, so it has AC and DC compatible input functions, and the input voltage range is wide; YK-AD series adjustable constant-current DC switching power supply adopts advanced switching power supply control technology and Components, as well as careful design, the whole machine is small in size, light in weight and high in efficiency, which ensures the stability and reliability of long-term full-load operation.
High voltage DC switching power supply function
(1) Using high-frequency switching power supply technology, it has the characteristics of small size, light weight, high efficiency and good reliability.
(2) Working mode: long-term full-load continuous work, allowing long-term short-circuit or short-circuit startup under any conditions.
(3) Alarm function: It has over-current and short-circuit alarm functions.
(4) Preview function: Overvoltage and current Limit setting, with preview function.
(5) Constant voltage and constant current are automatically switched, and the voltage and current are steplessly adjustable from zero to the rated value, referred to as continuously adjustable.
(6) Protection function: It has over-voltage, over-current, phase loss, over-temperature and short-circuit protection functions.
(7) High-frequency switching DC power supply, output voltage 0-10KV, output current 0-100A, output power <100KW optional.
(8) It can be equipped with optional functional components such as RS-485, time controller, 0~10V (or 0~5V) external power supply control module, etc., to form a high degree of intelligence and various power supplies for different purposes.
Technical indicators of high voltage DC switching power supply
Load effect: ≤0.1%
Source effect: ≤0.1%
Soft start time: >3s
Insulation aging, tantalum electrolysis empowerment, electrical maintenance, laboratory, motor aging, measuring equipment, factory electrical equipment matching, oven and environmental testing machine power supply, and all other places that require high voltage and high current.
