Total microscope magnification: 30X ordinary small tool microscope IM
Eyepiece: 15X
Objective: 2X
Measuring range: 50x50mm (2"x2")
Measurement accuracy: 0.01mm
The movement of the micrometer head of the reading device: 25mm (1")
Reading handwheel grid value: 0.002mm (0.0001")
Goniometer eyepiece division value: 6′
Angle range: 0-360°
Stage size: 152xl52mm
Effective size of load glass: 96mmx96mm
Maximum load (on glass): 5kg
Focusing method: manual, the maximum height of the workpiece is 110mm
Lighting device: transmission, with green filter, adjustable brightness,
Single lamp oblique reflection lighting, brightness adjustable, light source 24V2W
Instrument weight: 15kg
