Principle analysis of magnetic eddy current dual purpose coating thickness gauge
MC-3000F/N magnetic and non magnetic dual purpose coating thickness gauge, equipped with N/F probe, cleverly combines the eddy current thickness gauge with the magnetic coating thickness gauge. Users can choose any ferromagnetic thickness measuring probe or eddy current thickness measuring probe according to on-site needs to measure the coating thickness on magnetic or non magnetic metals. Greatly increased the application range of the instrument. This type of coating thickness gauge can conveniently and non-destructive measure the thickness of non-magnetic coatings on ferromagnetic materials, such as zinc, copper, chromium and other coatings on steel surfaces or coatings such as paint, enamel, fiberglass, spray molding, asphalt, etc. It can also conveniently and non-destructive measure the thickness of non-conductive coatings on non magnetic metal substrates, such as paints, rubber, plastics, oxide films, etc. on metals such as copper, aluminum, zinc, tin, etc. This instrument is widely used in industries such as machinery, automobiles, shipbuilding, petroleum, chemicals, electroplating, spray molding, enamel, plastics, etc. This model of coating thickness gauge adopts * *'s deviation automatic tracking technology to make the measurement values more accurate. The probe is processed using German process standards, and new alloy materials are used to greatly improve the service life and accuracy of the probe.
Performance indicators of MC-3000F/N magnetic and non magnetic dual purpose coating thickness gauge:
Basic measurement modes: conventional mode, minimum value mode, statistical mode.
Monitoring and measurement mode: can be set for difference and upper and lower limit alarm settings.
You can choose to delete individual stored data, a certain set of data, or * * all data.
Can perform zero point calibration, two point calibration, and system calibration.
The shutdown mode can be set, with backlight on or off, to restore the factory state.
It can print stored values and statistical values.
There are 6 groups of data stored in groups, with 99 measurement points stored in each group.
You can view and store measured values in groups.
Technical parameters of MC-3000F/N magnetic and non magnetic dual purpose coating thickness gauge
Fe probe measurement range: 0-1200um
NF probe measurement range: 0-1200um
High display accuracy: 0.1 um
Under voltage display: The under voltage indicator icon is displayed in the upper left corner
Display method: 128 * 64 dot matrix LCD, graphic display
Size/Weight: 146 * 81 * 30mm 260 grams
