Scope of application of optical multimeter
DMC-2C type optical multimeter introduction in a DMC-2C type optical multimeter, focusing on several functions: (1) can accurately measure the value of optical power. In the wavelength range of 850nm ~ 1700nm, to pw, nw, mw, dBm display, resolution 0.001. (2) There is a fixed communication on the commonly used dual-wavelength 1310/1550nm light source output, the light source output power ≥ -8dBm (should be adjustable by the user requirements of the size of the optical power output). Stability is higher than the national standard.
In a DMC-2C type optical multimeter, focusing on several functions:
(1) can accurately measure the optical power value. In the wavelength range of 850nm ~ 1700nm, to pw, nw, mw, dBm display, 0.001.
(2) There is a fixed communication on the commonly used dual-wavelength 1310/1550nm light source output, light source output power ≥ -8dBm (adjustable optical power output size at the request of the user). Stability is higher than the national standard.
(3) optical fibre identification function: built-in 650nm light source, strong power output ≥ 0dBm, test distance 4 ~ 5km, is the right hand of the project, is a powerful complement to the OTDR blind, in the engineering use rate even more than the optical power meter.
(4) Relative value measurement function: this is the key of this instrument leading similar instruments at home and abroad. The use of highly stable light source, in conjunction with the optical power test, can accurately measure the optical attenuation value of the optical live connector, fibre optic pigtail or long-distance optical fibre, in order to judge its communication performance is good or bad, and decide to abandon it.
An optical multimeter with such a perfect performance saves friends from the tedious selection work of separate optical power meter or light source, and what's more, you will be surprised that its price is also lower than the imported single-wavelength 1310/1550nm light source from abroad, and even lower than an imported optical power meter.
Scope of application
Optical fibre communication, optical fibre computer network
Fibre optic CATV network
Optical sensing technology and optical device manufacturing
Basic Functions
Can be used as 1310nm highly stable light source
Can be used as 1550nm high stability light source
Can be used as a precision optical power meter
Fibre identification function: High-power red light output, fibre identification function over 4~5km (light output through the quasi-value head has the function of aggregation).
