Simple laser rangefinder principle and application explanation
Laser caliper is a high-tech product that integrates optics and electronics. By using laser scanning, high-speed, high-precision, non-contact measurement of circular objects on the production line is achieved. Due to the non-contact measurement points, there is no interference to the objects being measured, making it very suitable for hot, soft, moving, and vibrating objects.
The laser caliper can preset the nominal value and limit deviation of the outer diameter size within the measurement range. The copper sleeve thermometer [/url] processes the measurement signal in real time through a microcomputer, displays the measurement results digitally, emits an out of tolerance light alarm, and marks the preset nominal value. It outputs an analog signal of the deviation, adjusts the relevant parameters of the production equipment, realizes the closed-loop of the production line, improves product quality, and saves raw materials.
The laser caliper has strong self checking function, and can diagnose faults on its own. The cause of the fault is displayed on the monitor. The operator can also input diagnostic commands through the keyboard for diagnosis. This instrument can operate continuously, stably, and reliably.
Laser caliper can be widely used in production lines such as wires, cables, steel wires, rubber tubes, rubber rods, medical glass tubes, etc., to achieve automatic control of outer diameter. In the mechanical manufacturing industry, for a large number of parts that require inspection, this instrument can be used to inspect production lines, measure and sort the parts.
