Upright metallographic microscope reflective microscope
Main uses and characteristics
Reflective microscope and upright metallographic microscope are commonly used professional experimental instruments in departments such as geology, mineral resources, metallurgy, and related higher education institutions. They are suitable for observing transparent, semi transparent, or opaque materials in the electronic, metallurgical, chemical, and instrumentation industries, such as metal ceramics, integrated blocks, printed circuit boards, liquid crystal boards, thin films, fibers, coatings, and other non-metallic materials. They are also suitable for observation and analysis in pharmaceutical, agricultural and forestry, schools, and scientific research departments. It is also an ideal instrument for research in metallurgy, mineralogy, precision engineering, electronics, and other fields.
The DMM-200C computerized three lens reflective microscope (upright metallographic microscope) is a high-tech product developed by combining advanced optical microscopy technology, advanced photoelectric conversion technology, and computer imaging technology. It can be used to manually observe metallographic images, as well as conveniently and timely observe metallographic images on computer monitors. It can also capture and record metallographic images at any time for analysis, rating, and other purposes of metallographic diagrams. High pixel metallographic photos can also be saved or printed.
2, The main technical specifications of reflective microscope instruments
Eyepiece large field WF10X (diameter 18mm) objective flat field achromatic (without cover glass) magnification/numerical aperture working distance PL5X/0.1218.3PLL10X/0.258.9PLL40X/0.60 (spring) 3.7PL60X/0.85 (spring) 0.26 eyepiece cylinder three eyepiece rotary shaft type, tilted 30 degrees, including polarization detection plate worktable longitudinal movement: 50mm lateral movement: 70mm instrument body coarse adjustment and fine adjustment handwheel, fine adjustment grid value of 0.002MM (base and bracket) Polarization device can be inserted polarization plate, vertical lighting device, can perform general metallographic analysis and particle analysis testing, and can also detect opacity. Analyze and observe the object. Filter group blue, yellow, green, frosted focusing mechanism coaxial coarse micro focusing mechanism, focusing range 15mm micro grid value 2 μ m lighting system falling illumination 6V20W, halogen lamp, brightness adjustable, with polarizer reflective microscope system components 1. Metallographic microscope DMM-200 2. Computer adapter mirror 3. Color camera (CCD) 4. A/D converter (color image acquisition equipment) 5. Computer (optional) light microscope selection part 1. Metallographic analysis software 2. Flat field eyepiece: 16 x 32 million pixel imager, 3 million pixel imager, 4 million pixel imager Reflective display microscope comparison of similar instruments 1. DMM-200 M-200C upright metallographic microscope 2, DMM-200D computerized metallographic microscope 3, DMM-220C computerized metallographic microscope 4 DMM-220D Digital Metallographic Microscope 6. Reflective Microscope Accessories 1. Reflective Microscope Bulb 2. Reflective Microscope Light Source 3. Polarizing Device 4. Reflective Microscope Camera System
