What is a metallographic microscope? What types of metallographic microscopes are commonly used?
Microscopes used to study metallographic structures are called metallographic microscopes.
It differs from a biological microscope in that it uses reflected light to observe opaque objects.
There are many types of metallographic microscopes,
There are several types of metallographic microscopes commonly used.
(1) Portable small metallographic microscope
This type of metallographic microscope is simple in structure and easy to use, and is very suitable for heat treatment vehicles
It can be observed in the bright area for on-site inspection work.
(2) Upright Metallographic Microscope
The difference between this type of microscope and the desktop is that the objective lens is upward when observing, while the surface of the object is downward.
And the accuracy is high, the application range is wide, it can be observed in the bright area,
It can also be observed with dark field.
(3) Inverted metallographic microscope/also called horizontal (horizontal) metallographic microscope
Its structure is roughly the same as that of the vertical type, and it can be used in various lighting methods for various lighting effects.
Large multiple observation, the highest multiple can reach 2500
